2,600 mm
4,225 mm
1,555 mm
1,590 (1600) mm
1,810 mm
| Engine, Performance & Transmission | |
|---|---|
| Engine type | G16Df Gasoline |
| Capacity | 1,597 CC |
| Max. HP | 128 PS / 6,000 rpm |
| Max. Torque | 160 Nm / 4,600 rpm |
| Compression ration | 10.5 : 1 |
| Fuel tank capacity | 47 L |
| Transmission | 6 Speed Automatic transmission / steptronic |
| Weight | |
|---|---|
| Kerb weight | 1,335 ~1,402 KG |
| Gross vehicle weight | 1,880 Kg |
| Gross trailer weight | 1,000 Kg (Braked) |
| Gross trailer weight | 500 Kg (unbreaked) |
| Dimensions | |
|---|---|
| Overall length | 4,225 mm |
| Overall width | 1,810 mm |
| Overall height | 1,613 mm (1,621 mm with roof rails) |
| Wheel base | 2,600 mm |
| Approach angle | 20.5 ° |
| Departure angle | 28.0 ° |
| Min. clearnace | 178 mm |
| Min. turning radius | 5.3 m |
| Luggage capacity (VDA) | 427 L |
| Suspension & brakes | |
|---|---|
| Front suspension | Macpherson Strut |
| 2WD Rear suspension | Torsion bar |
| 4WD Rear suspension | Rear 4 link suspension |
| Front brakes | Ventilated Front discs |
| Rear brakes | Discs |
| Equipments | COMFORT | SPORT | SPORT 4x4 |
|---|---|---|---|
| price | - | - | - |
| Driver Airbag |
|
|
|
| Dual Airbag with Passenger Airbag off Switch |
|
|
|
| ABS + EBD |
|
|
|
| Smart Driving Modes (Winter/ Power/ Economy) |
|
|
|
| 4WD + REAR 4 LINK SUSPENSION |
|
|
|
| Front Ventilated brake disc/ rear brake disc |
|
|
|
| EPS (Electric Power Steering) |
|
|
|
| Smart Steering Mode (Normal, Sport, Comfort) |
|
|
|
| Steering Wheel (D-Cut) Design |
|
|
|
| Leather s/wheel |
|
|
|
| Steering Wheel Position Indicator in the Cluster |
|
|
|
| Steering Wheel Remocon |
|
|
|
| Cruise Control |
|
|
|
| 16" Alloy Wheels 205/60 R16 |
|
|
|
| 18" Diamond Cut (2-Tone) Alloy Wheels + 215/50R Tyres - Depends on Exterior Color Package |
|
|
|
| Temporary (125/80 R16) W/Steel Wheel |
|
|
|
| Outside Mirror Self-Heating & Elec. Adj. |
|
|
|
| O/S Mirror Elec. Foldable + Built In LED Side Repeater |
|
|
|
| Beltline Sus. Molding - Hood/ Doors |
|
|
|
| Fashion Rail |
|
|
|
| Privacy Glass (RR DR, QTR, Tailgate) |
|
|
|
| Power Sliding Sun roof |
|
|
|
| 60:40 Split Folding Rear Seat |
|
|
|
| Ventilated (Beige/ Black) seat cover - Depends on the exterior color package |
|
|
|
| Height Adj. Seat w/ sliding headrest (Driver) |
|
|
|
| Rear Center armrest w/cupholder |
|
|
|
| ISO-FIX (Child Seat Lock) |
|
|
|
| Luggage cover roll screen |
|
|
|
| Sun Roof |
|
|
|
| Sun visor with vanity mirror & illumination (both) |
|
|
|
| Center Console with arm rest (front) |
|
|
|
| Inside Door Handle - Silver |
|
|
|
| Inside Door Handle - Chrome |
|
|
|
| Mobile Ash Tray & Lighter |
|
|
|
| Leather Door Trim Inserts |
|
|
|
| 1-Touch Triple Signal Indicator |
|
|
|
| Front Door Hazard Lamp |
|
|
|
| Floor Mat |
|
|
|
| On Board Computer |
|
|
|
| Projection Headlamp & Front/ Rear Fog Lamps |
|
|
|
| Daytime Running System - LED |
|
|
|
| Parking Aid System - Front + Rear |
|
|
|
| Rear Combi Lamp - Tail, Stop LED |
|
|
|
| LED Fog Lamps |
|
|
|
| Immobilizer + Panic Alarm |
|
|
|
| Dual Remote Keys |
|
|
|
| Dual Smart Key + Start/ Stop Engine |
|
|
|
| Center High Mounted Stop Lamp |
|
|
|
| RR Spoiler With LED stop Light |
|
|
|
| Power Window, Driver 1-touch Down |
|
|
|
| Intermittent Rear Wiper |
|
|
|
| Digital Clock |
|
|
|
| Front & Trunk Power Outlet 12V |
|
|
|
| Instrument Panel & Door Mood Lamp |
|
|
|
| Air Conditioner |
|
|
|
| Outside Tempreature Display |
|
|
|
| MP3 Audio w/Bluetooth Handsfree & USB & AUX jack |
|
|
|
| Smart Audio Package + HD 8" Smart Audio (RDS) w/Bluetooth Handsfree & HDMI & USB |
|
|
|
| Rear View Camera |
|
|
|
